Authoring the App Tour

This page explains how the App Tour was generated and how to regenerate or refresh it.

Two workflows​

Full regenerate — prose + images. One-shot, agent-driven. Use after significant UI redesigns when the old prose no longer describes what's on screen.

Refresh screenshots only — images only. Deterministic, bash-driven. Use after routine UI tweaks when the old prose is still accurate.

Prerequisites​

  • pnpm install completed in the repo root.

  • uvx available (for the refresh script).

  • Chromium available (Playwright MCP for agent authoring; Rodney's own Chrome for the refresh script).

  • .env present. Start by copying .env.example:

    cp .env.example .env

    If TRAKRF_DOCS_USER_EMAIL / TRAKRF_DOCS_USER_PASSWORD are blank, the agent-driven authoring pass will create a new account on the preview app and write the creds back into .env.

Refresh screenshots only​

bash scripts/refresh-screenshots.sh

That's the whole workflow. The script logs in, navigates to each of the 9 tabs, captures desktop (1440×900) and mobile (390×844) PNGs into static/img/app-tour/, and exits. Prose in docs/app-tour/*.md is not touched. Commit the image diff as feat: refresh app-tour screenshots.

If login selectors change upstream (the script uses input[type=email], input[type=password], button[type=submit] against app.preview.trakrf.id), update those in scripts/refresh-screenshots.sh and re-run.

Full regenerate (agent-driven)​

Ask Claude Code (or any agent with Playwright MCP) to follow this recipe:

  1. Ensure .env exists and contains TRAKRF_PREVIEW_URL. Credentials may be blank on first run.
  2. If credentials are blank: navigate to ${TRAKRF_PREVIEW_URL}/#signup (the "Sign up" link on the login page doesn't consistently route via a click — go to the URL directly). Create an account with a generated email (docs-tour-<YYYYMMDD>@example.com), an organization name like "TrakRF Docs Tour", and a random password. Persist email + password into .env.
  3. For each of the 9 tabs, in nav order — home, inventory, locate, barcode, assets, locations, reports, settings, help:
    • Resize the browser to 1440×900.
    • Navigate to ${TRAKRF_PREVIEW_URL}/#<tab>.
    • Wait 1–2 seconds for the page to stabilize.
    • Take a screenshot into static/img/app-tour/<tab>-desktop.png.
    • Resize to 390×844, navigate again to force responsive remount, wait, screenshot into <tab>-mobile.png.
    • Observe the page. Write 2–4 sentences into the "What this page does" section of docs/app-tour/<tab>.md. List concrete controls, empty-state copy, and any visible device-status indicators.
    • Write 1–2 sentences into the "How it fits in the app" section connecting this tab to adjacent tabs or a workflow.
  4. Run pnpm build to verify. Then pnpm dev and eyeball the site-map + a few detail pages.
  5. Commit images and prose separately for a clean history.

Things to know​

  • Playwright MCP saves screenshots to the working directory, not a subfolder. Each browser_take_screenshot drops the PNG in the repo root; move it into static/img/app-tour/ with the correct name after each capture.
  • Signup URL. Clicking the "Sign up" link from the login form does not consistently route on app.preview.trakrf.id — navigate directly to /#signup instead.
  • Empty-state honesty. A fresh docs user owns no assets/locations/reports, so those tabs show "no data yet" UIs. A browser without a connected RFID reader shows "connect a device" states on Inventory / Locate / Barcode / Settings. Both are informative and match the new-user experience. If you want populated screenshots later, seed the account before the capture.
  • Mobile viewport caveat. Rodney's screenshot -w -h resizes the viewport before each capture; if the app's layout depends on viewport size at mount time, the mobile shot may be a scaled desktop. If that happens, the fix is in scripts/refresh-screenshots.sh: either re-navigate after resize (the agent authoring recipe already does this) or drive viewport emulation via Rodney's JS bridge. Playwright MCP, used for the authoring pass, handles this correctly already.
  • Credentials are local. .env is gitignored. Never commit it. Never paste credentials into commit messages or PR descriptions.
  • Showboat is not used. The original TRA-347 scope mentioned Showboat alongside Rodney. In practice, Showboat's exec/verify model targets executable docs, not screenshot tours — so this tooling uses Rodney for refresh and Playwright MCP (via Claude Code) for authoring, skipping Showboat entirely.
